84 Opaque PVC slats for in-ground automatic slatted covers
Opaque 84 PVC grey slats for in-ground automatic slatted covers
To get a price
and place an order,
Click here for more detail
09 70 72 5000
From monday to friday 08:00 am- 6:00 pm See the peak times
Product Bonuses
THE PRODUCT BONUSES
- Modern and sleek design.
- Flat slat for a perfect finish on the water surface.
- Quick and easy to install.
- Patented system.
POOL TYPE
- Available for all covers (submerged, above-ground).
- For pools up to 5.00 m wide*.
MODERN DESIGN
- A flexible inter-slat connection with a "boat deck seal" effect.
- The number of joints and thus the areas prone to dirt is reduced by 5 times compared to a standard slat.
CONVENIENT ASSEMBLY AND DISASSEMBLY
- The sliding assembly system is patented, making it easier to assemble and disassemble the slats. This assembly is made possible thanks to removable fins.
ADAPTABLE TO ALL COVER MECHANISMS
- Reduced winding diameter, identical to that of the 69 PVC opaque slat.
1 - COMPATIBILITY
- The 84 PVC opaque slats are compatible with all covers up to 5.00 m wide and with the Pushlock attachment system only.
2 - SLAT ASSEMBLY
- The cover assembly is done by sliding the slats into place. The presence of the L4 modules (wide) makes the overall installation much faster.
- For your information, the clip-on assembly system is not available for this product.
2 SLAT MODULES:
L4 MODULE
Dimensions: width 332 mm. The L4 module (composed of a single element) forms the core of the cover. It allows for covering a large area in one piece and has a flexible joint between slats.
L1 MODULE
Dimensions: width 84 mm. Used for the ends of the cover and to adjust the length.
POOL TYPE
- Available for all covers (submerged, above-ground).
- For pools up to 5.00 m wide*.
MODERN DESIGN
- A flexible inter-slat connection with a "boat deck seal" effect.
- The number of joints and thus the areas prone to dirt is reduced by 5 times compared to a standard slat.
CONVENIENT ASSEMBLY AND DISASSEMBLY
- The sliding assembly system is patented, making it easier to assemble and disassemble the slats. This assembly is made possible thanks to removable fins.
ADAPTABLE TO ALL COVER MECHANISMS
- Reduced winding diameter, identical to that of the 69 PVC opaque slat.
1 - COMPATIBILITY
- The 84 PVC opaque slats are compatible with all covers up to 5.00 m wide and with the Pushlock attachment system only.
2 - SLAT ASSEMBLY
- The cover assembly is done by sliding the slats into place. The presence of the L4 modules (wide) makes the overall installation much faster.
- For your information, the clip-on assembly system is not available for this product.
2 SLAT MODULES:
L4 MODULE
Dimensions: width 332 mm. The L4 module (composed of a single element) forms the core of the cover. It allows for covering a large area in one piece and has a flexible joint between slats.
L1 MODULE
Dimensions: width 84 mm. Used for the ends of the cover and to adjust the length.
Technical specifications
EXTRUDED PVC SLATS:
- Thickness 11.40 mm.
- Lead-free additive.
- Resistance to stains caused by organic deposits.
- Material complies with the aging resistance requirements defined in standard NFT-54-405-1: 2013.
- UV treatment.
END CAPS:
- Soldered to the ends of the slats.
FINS:
- Removable to facilitate the assembly and disassembly of the slats.
- 3 available sizes (standard, S & XL) for optimal adjustment of the slat dimensions. By default, our orders are delivered with standard fins. The "XL" and "S" fins allow for an adjustment of +/- 1 cm per side (i.e., 2 cm per cover).
- Shaped fins for curves and stairs.
Colour
COLOURS
White
Grey
